Kubernetes Cookbook: Practical solutions to container orchestration , Second Edition

The Kubernetes master is the main component of the Kubernetes cluster. It serves several functionalities, such as the following:

The following diagram shows how master daemons work together to fulfill the aforementioned functionalities:

There are several daemon processes that form the Kubernetes master's functionality, such as kube-apiserver, kube-scheduler and kube-controller-manager. Hypercube, the wrapper binary, can launch all these daemons.

In addition, the Kubernetes command-line interface, kubect can control the Kubernetes master functionality.

The API server provides an HTTP- or HTTPS-based RESTful API, which is the hub between Kubernetes components, such as kubectl, the scheduler, the replication controller, the etcd data store, the kubelet and kube-proxy, which runs on Kubernetes nodes, and so on.

The scheduler helps to choose which container runs on which nodes. It is a simple algorithm that defines the priority for dispatching and binding containers to nodes. For example:

The controller manager performs cluster operations. For example:

After you install the Kubernetes master, you can use the Kubernetes command-line interface, kubectl, to control the Kubernetes cluster. For example, kubectl get cs returns the status of each component. Also, kubectl get nodes returns a list of Kubernetes nodes:

//see the Component Statuses
# kubectl get cs
NAME                 STATUS    MESSAGE              ERROR
controller-manager   Healthy   ok                   nil
scheduler            Healthy   ok                   nil
etcd-0               Healthy   {"health": "true"}   nil


//see the nodes
# kubectl get nodes
NAME          LABELS                           STATUS    AGE
kub-node1   kubernetes.io/hostname=kub-node1   Ready     26d
kub-node2   kubernetes.io/hostname=kub-node2   Ready     26d

The Kubernetes node is a slave node in the Kubernetes cluster. It is controlled by the Kubernetes master to run container applications using Docker (http://docker.com) or rkt (http://coreos.com/rkt/docs/latest/). In this book, we will use the Docker container runtime as the default engine.

The following diagram displays the role and tasks of daemon processes in the node:

The node also has two daemon processes, named kubelet and kube-proxy, to support its functionalities.

kubelet is the main process on the Kubernetes node that communicates with the Kubernetes master to handle the following operations:

The proxy handles the network proxy and load balancer for each container. It changes Linux iptables rules (nat table) to control TCP and UDP packets across the containers.

After starting the kube-proxy daemon, it configures iptables rules; you can use iptables -t nat -L or iptables -t nat -S to check the nat table rules, as follows:

//the result will be vary and dynamically changed by kube-proxy
# sudo iptables -t nat -S
-P PREROUTING ACCEPT
-P INPUT ACCEPT
-P OUTPUT ACCEPT
-P POSTROUTING ACCEPT
-N DOCKER
-N FLANNEL
-N KUBE-NODEPORT-CONTAINER
-N KUBE-NODEPORT-HOST
-N KUBE-PORTALS-CONTAINER
-N KUBE-PORTALS-HOST
-A PREROUTING -m comment --comment "handle ClusterIPs; NOTE: this must be before the NodePort rules" -j KUBE-PORTALS-CONTAINER
-A PREROUTING -m addrtype --dst-type LOCAL -m comment --comment "handle service NodePorts; NOTE: this must be the last rule in the chain" -j KUBE-NODEPORT-CONTAINER
-A PREROUTING -m addrtype --dst-type LOCAL -j DOCKER
-A OUTPUT -m comment --comment "handle ClusterIPs; NOTE: this must be before the NodePort rules" -j KUBE-PORTALS-HOST
-A OUTPUT -m addrtype --dst-type LOCAL -m comment --comment "handle service NodePorts; NOTE: this must be the last rule in the chain" -j KUBE-NODEPORT-HOST
-A OUTPUT ! -d 127.0.0.0/8 -m addrtype --dst-type LOCAL -j DOCKER
-A POSTROUTING -s 192.168.90.0/24 ! -o docker0 -j MASQUERADE
-A POSTROUTING -s 192.168.0.0/16 -j FLANNEL
-A FLANNEL -d 192.168.0.0/16 -j ACCEPT
-A FLANNEL ! -d 224.0.0.0/4 -j MASQUERADE

etcd (https://coreos.com/etcd/) is the distributed key-value data store. It can be accessed via the RESTful API to perform CRUD operations over the network. Kubernetes uses etcd as the main data store.

You can explore the Kubernetes configuration and status in etcd (/registry) using the curl command, as follows:

//example: etcd server is localhost and default port is 4001
# curl -L http://127.0.0.1:4001/v2/keys/registry
{"action":"get","node":{"key":"/registry","dir":true,"nodes":[{"key":"/registry/namespaces","dir":true,"modifiedIndex":6,"createdIndex":6},{"key":"/registry/pods","dir":true,"modifiedIndex":187,"createdIndex":187},{"key":"/registry/clusterroles","dir":true,"modifiedIndex":196,"createdIndex":196},{"key":"/registry/replicasets","dir":true,"modifiedIndex":178,"createdIndex":178},{"key":"/registry/limitranges","dir":true,"modifiedIndex":202,"createdIndex":202},{"key":"/registry/storageclasses","dir":true,"modifiedIndex":215,"createdIndex":215},{"key":"/registry/apiregistration.k8s.io","dir":true,"modifiedIndex":7,"createdIndex":7},{"key":"/registry/serviceaccounts","dir":true,"modifiedIndex":70,"createdIndex":70},{"key":"/registry/secrets","dir":true,"modifiedIndex":71,"createdIndex":71},{"key":"/registry/deployments","dir":true,"modifiedIndex":177,"createdIndex":177},{"key":"/registry/services","dir":true,"modifiedIndex":13,"createdIndex":13},{"key":"/registry/configmaps","dir":true,"modifiedIndex":52,"createdIndex":52},{"key":"/registry/ranges","dir":true,"modifiedIndex":4,"createdIndex":4},{"key":"/registry/minions","dir":true,"modifiedIndex":58,"createdIndex":58},{"key":"/registry/clusterrolebindings","dir":true,"modifiedIndex":171,"createdIndex":171}],"modifiedIndex":4,"createdIndex":4}}

Network communication between containers is the most difficult part. Because Kubernetes manages multiple nodes (hosts) running several containers, those containers on different nodes may need to communicate with each other.

If the container's network communication is only within a single node, you can use Docker network or Docker compose to discover the peer. However, along with multiple nodes, Kubernetes uses an overlay network or container network interface (CNI) to achieve multiple container communication.

Let's get the Kubernetes packages first! The repository for downloading needs to be set in the source list of the package management system. Then, we are able to get them installed easily through the command-line.

$ sudo apt-get update && sudo apt-get install -y apt-transport-https

$ curl -s https://packages.cloud.google.com/apt/doc/apt-key.gpg | sudo apt-key add -
OK

$ sudo bash -c 'echo "deb http://apt.kubernetes.io/ kubernetes-xenial main" > /etc/apt/sources.list.d/kubernetes.list'

// on Kubernetes master
$ sudo apt-get update && sudo apt-get install -y kubelet kubeadm kubectl
// on Kubernetes node
$ sudo apt-get update && sudo apt-get install -y kubelet

$ sudo vim /etc/yum.repos.d/kubernetes.repo
[kubernetes]
name=Kubernetes
baseurl=https://packages.cloud.google.com/yum/repos/kubernetes-el7-x86_64
enabled=1
gpgcheck=1
repo_gpgcheck=1
gpgkey=https://packages.cloud.google.com/yum/doc/yum-key.gpg
       https://packages.cloud.google.com/yum/doc/rpm-package-key.gpg

// on Kubernetes master
$ sudo yum install -y kubelet kubeadm kubectl
// on Kubernetes node
$ sudo yum install -y kubelet

// take it easy! server connection failed since there is not server running
$ kubectl version
Client Version: version.Info{Major:"1", Minor:"10", GitVersion:"v1.10.2", GitCommit:"81753b10df112992bf51bbc2c2f85208aad78335", GitTreeState:"clean", BuildDate:"2018-04-27T09:22:21Z", GoVersion:"go1.9.3", Compiler:"gc", Platform:"linux/amd64"}
The connection to the server 192.168.122.101:6443 was refused - did you specify the right host or port?

Before running up the whole system by kubeadm, please check that Docker is running on your machine for Kubernetes. Moreover, in order to avoid critical errors while executing kubeadm, we will show the necessary service configuration on both the system and kubelet. As well as the master, please set the following configurations on the Kubernetes nodes to get kubelet to work fine with kubeadm.

// check the state of SELinux, if it has already been disabled, bypass below commands
$ sestatus

// disable SELinux through command
$  sudo setenforce 0
// or modify the configuration file
$ sudo sed –I 's/ SELINUX=enforcing/SELINUX=disabled/g' /etc/sysconfig/selinux

// reboot is required
$ sudo reboot

// enable the parameters by setting them to 1
$ sudo bash -c 'echo "net.bridge.bridge-nf-call-ip6tables = 1" > /etc/sysctl.d/k8s.conf'
$ sudo bash -c 'echo "net.bridge.bridge-nf-call-iptables = 1" >> /etc/sysctl.d/k8s.conf'
// reload the configuration
$ sudo sysctl --system

Now we can start the service. First enable and then start kubelet on your Kubernetes master machine:

$ sudo systemctl enable kubelet && sudo systemctl start kubelet

While checking the status of kubelet, you may be worried to see the status displaying activating (auto-restart); and you may get further frustrated to see the detail logs by the journalctl command, as follows:

error: unable to load client CA file /etc/kubernetes/pki/ca.crt: open /etc/kubernetes/pki/ca.crt: no such file or directory

Don't worry. kubeadm takes care of creating the certificate authorities file. It is defined in the service configuration file, /etc/systemd/system/kubelet.service.d/10-kubeadm.conf by argument KUBELET_AUTHZ_ARGS. The kubelet service won't be a healthy without this file, so keep trying to restart the daemon by itself.

Go ahead and start all the master daemons via kubeadm. It is worth noting that using kubeadm requires the root permission to achieve a service level privilege. For any sudoer, each kubeadm would go after the sudo command:

$ sudo kubeadm init

And you will see the sentence Your Kubernetes master has initialized successfully! showing on the screen. Congratulations! You are almost done! Just follow the information about the user environment setup below the greeting message:

$ mkdir -p $HOME/.kube
$ sudo cp -i /etc/kubernetes/admin.conf $HOME/.kube/config
$ sudo chown $(id -u):$(id -g) $HOME/.kube/config

The preceding commands ensure every Kubernetes instruction is fired by your account execute with the proper credentials and connects to the correct server portal:

// Your kubectl command works great now
$ kubectl version
Client Version: version.Info{Major:"1", Minor:"10", GitVersion:"v1.10.2", GitCommit:"81753b10df112992bf51bbc2c2f85208aad78335", GitTreeState:"clean", BuildDate:"2018-04-27T09:22:21Z", GoVersion:"go1.9.3", Compiler:"gc", Platform:"linux/amd64"}
Server Version: version.Info{Major:"1", Minor:"10", GitVersion:"v1.10.2", GitCommit:"81753b10df112992bf51bbc2c2f85208aad78335", GitTreeState:"clean", BuildDate:"2018-04-27T09:10:24Z", GoVersion:"go1.9.3", Compiler:"gc", Platform:"linux/amd64"}

More than that, kubelet goes into a healthy state now:

// check the status of kubelet
$ sudo systemctl status kubelet
...
Active: active (running) Mon 2018-04-30 18:46:58 EDT; 2min 43s ago
...

After the master of the cluster is ready to handle jobs and the services are running, for the purpose of making containers accessible to each other through networking, we need to set up the network for container communication. It is even more important initially while building up a Kubernetes cluster with kubeadm, since the master daemons are all running as containers. kubeadm supports the CNI (https://github.com/containernetworking/cni). We are going to attach the CNI via a Kubernetes network add-on.

There are many third-party CNI solutions that supply secured and reliable container network environments. Calico (https://www.projectcalico.org), one CNI provide stable container networking. Calico is light and simple, but still well implemented by the CNI standard and integrated with Kubernetes:

$ kubectl apply -f https://docs.projectcalico.org/v2.6/getting-started/kubernetes/installation/hosted/kubeadm/1.6/calico.yaml

Here, whatever your host OS is, the command kubectl can fire any sub command for utilizing resources and managing systems. We use kubectl to apply the configuration of Calico to our new-born Kubernetes.

More advanced management of networking and Kubernetes add-ons will be discussed in Chapter 7, Building Kubernetes on GCP.

Let's log in to your Kubernetes node to join the group controlled by kubeadm:

$ sudo systemctl enable kubelet && sudo systemctl start kubelet

// on master node, list the token you have in the cluster
$ sudo kubeadm token list
TOKEN                     TTL       EXPIRES                     USAGES                   DESCRIPTION                                                EXTRA GROUPS
da3a90.9a119695a933a867   6h       2018-05-01T18:47:10-04:00   authentication,signing   The default bootstrap token generated by 'kubeadm init'.   system:bootstrappers:kubeadm:default-node-token

// The master IP is 192.168.122.101, token is da3a90.9a119695a933a867, 6443 is the port of api server.
$ sudo kubeadm join --token da3a90.9a119695a933a867 192.168.122.101:6443 --discovery-token-unsafe-skip-ca-verification

// fire kubectl subcommand on master
$ kubectl get nodes
NAME       STATUS    ROLES     AGE       VERSION
ubuntu01   Ready     master    11h       v1.10.2
ubuntu02   Ready     <none>    26s       v1.10.2

Well done! No matter if whether your OS is Ubuntu or CentOS, kubeadm is installed and kubelet is running. You can easily go through the preceding steps to build your Kubernetes cluster.

You may be wondering about the flag discovery-token-unsafe-skip-ca-verification used while joining the cluster. Remember the kubelet log that says the certificate file is not found? That's it, since our Kubernetes node is brand new and clean, and has never connected with the master before. There is no certificate file to find for verification. But now, because the node has shaken hands with the master, the file exists. We may join in this way (in some situation requiring rejoining the same cluster):

kubeadm join --token $TOKEN $MASTER_IPADDR:6443 --discovery-token-ca-cert-hash sha256:$HASH

The hash value can be obtained by the openssl command:

// rejoining the same cluster
$ HASH=$(openssl x509 -pubkey -in /etc/kubernetes/pki/ca.crt | openssl rsa -pubin -outform der 2>/dev/null | openssl dgst -sha256 -hex | sed 's/^.* //')
$ sudo kubeadm join --token da3a90.9a119695a933a867 192.168.122.101:6443 --discovery-token-ca-cert-hash sha256:$HASH

The easiest way to install Ansible, is to use pip, the Python package manager. Some of newer versions of Python have pip already (Python 2.7.9 or later and Python 3.4 or later):

//use capital V
$ pip -V
pip 9.0.1 from /Library/Python/2.7/site-packages (python 2.7)

//this result shows you don't have pip yet
$ pip -V
-bash: pip: command not found

//download pip install script
$ curl -LO https://bootstrap.pypa.io/get-pip.py


//run get-pip.py by privileged user (sudo)
$ sudo python get-pip.py
Collecting pip
  Downloading pip-9.0.1-py2.py3-none-any.whl (1.3MB)
    100% |################################| 1.3MB 779kB/s
Collecting wheel
  Downloading wheel-0.30.0-py2.py3-none-any.whl (49kB)
    100% |################################| 51kB 1.5MB/s
Installing collected packages: pip, wheel
Successfully installed pip-9.0.1 wheel-0.30.0


//now you have pip command
$ pip -V
pip 9.0.1 from /usr/lib/python2.7/site-packages (python 2.7)

Perform the following steps to install Ansible:

//ran by privileged user (sudo)
$ sudo pip install ansible

$ which ansible
/usr/bin/ansible

$ ansible --version
ansible 2.4.1.0

Next, according to kubespray's documentation (https://github.com/kubernetes-incubator/kubespray#requirements), it needs the python-netaddr package. This package can also be installed by pip, as shown in the following code:

$ sudo pip install netaddr

One more thing, as mentioned previously, Ansible is actually the ssh automation tool. If you log on to host via ssh, you have to have an appropriate credential (user/password or ssh public key) to the target machines. In this case, the target machines mean the Kubernetes master and nodes.

Due to security reasons, especially in the public cloud, Kubernetes uses only the ssh public key authentication instead of ID/password authentication.

To follow the best practice, let's copy the ssh public key from your Ansible machine to the Kubernetes master/node machines:

//with –q means, quiet output
$ ssh-keygen -q

//use ssh-agent to remember your private key and passphrase (if you set)
ansible_machine$ ssh-agent bash
ansible_machine$ ssh-add
Enter passphrase for /home/saito/.ssh/id_rsa: Identity added: /home/saito/.ssh/id_rsa (/home/saito/.ssh/id_rsa)


//logon from ansible machine to k8s machine which you copied public key
ansible_machine$ ssh 10.128.0.2
Last login: Sun Nov  5 17:05:32 2017 from 133.172.188.35.bc.googleusercontent.com
k8s-master-1$

Now you are all set! Let's set up Kubernetes using kubespray (Ansible) from scratch.

In order to perform the Ansible playbook, you need to maintain your own inventory file, which contains target machine IP addresses:

//copy sample to mycluster
ansible_machine$ cp -rfp inventory/sample inventory/mycluster

//edit hosts.ini
ansible_machine$ vi inventory/mycluster/hosts.ini

Note that hostname (my-master-1 and my-node-1) will be set by the kubespray playbook based on this hosts.ini, so feel free to assign a meaningful hostname.

Before running the kubespray playbook, let's check whether hosts.ini and Ansible itself work properly or not:

If you're unfortunate enough to see some errors, please refer to the following section to solve Ansible issues.

The ideal situation would be to use the same Linux distribution, version, settings, and logon user. However, the environment will be different based on policy, compatibility, and other reasons. Ansible is flexible and can support many use cases to run ssh and sudo.

Need to specify a sudo password

Based on your Linux machine setting, you may see the following error when adding the -b option. In this case, you need to type your password while running the sudo command:

In this case, add -K (ask for the sudo password) and run again. It will ask for your sudo password when running the Ansible command, as shown in the following screenshot:

Note

If your Linux uses the su command instead of sudo, adding --become-method=su to run the Ansible command could help. Please read the Ansible documentation for more details : http://docs.ansible.com/ansible/latest/become.html

my-master-1 ansible_ssh_host=10.128.0.2 ansible_user=kirito
my-node-1 ansible_ssh_host=10.128.0.4 ansible_user=asuna

my-master-1 ansible_ssh_host=10.128.0.2
my-node-1 ansible_ssh_host=10.128.0.4 ansible_port=10022

 Common ansible issue

Ansible is flexible enough to support any other situations. If you need any specific parameters to customize the ssh logon for the target host, read the Ansible inventory documentation to find a specific parameter: http://docs.ansible.com/ansible/latest/intro_inventory.html

In addition, Ansible has a configuration file, ansible.cfg, on top of the kubespray directory. It defines common settings for Ansible. For example, if you are using a very long username that usually causes an Ansible error, change ansible.cfg to set control_path to solve the issue, as shown in the following code:

[ssh_connection]
control_path = %(directory)s/%%h-%%r

If you plan to set up more than 10 nodes, you may need to increase ssh simultaneous sessions. In this case, adding the forks parameter also requires you to increase the ssh timeout from 10 seconds to 30 seconds by adding the timeout parameter, as shown in the following code:

[ssh_connection]
forks = 50
timeout = 30

The following screenshot contains all of the preceding configurations in ansible.cfg:

For more details, please visit the Ansible configuration documentation at http://docs.ansible.com/ansible/latest/intro_configuration.html

On the Kubernetes master, we can use kubectl run to create a certain number of containers. The Kubernetes master will then schedule the pods for the nodes to run, with general command formatting, as follows:

$ kubectl run <replication controller name> --image=<image name> --replicas=<number of replicas> [--port=<exposing port>]

The following example will create two replicas with the name my-first-nginx from the nginx image and expose port 80. We can deploy one or more containers in what is referred to as a pod. In this case, we will deploy one container per pod. Just like a normal Docker behavior, if the nginx image doesn't exist locally, it will pull it from the Docker Hub by default:


// run a deployment with 2 replicas for the image nginx and expose the container port 80
$ kubectl run my-first-nginx --image=nginx --replicas=2 --port=80
deployment "my-first-nginx" created

Error from server (AlreadyExists): deployments.extensions "my-first-nginx" already exists

Let's move on and see the current status of all the pods by kubectl get pods. Normally the status of the pods will hold on Pending for a while, since it takes some time for the nodes to pull the image from the registry:

// get all pods
$ kubectl get pods
NAME                              READY     STATUS    RESTARTS   AGE
my-first-nginx-7dcd87d4bf-jp572   1/1       Running   0          7m
my-first-nginx-7dcd87d4bf-ns7h4   1/1       Running   0          7m

You can also check the details about the deployment to see whether all the pods are ready:

// check the status of your deployment
$ kubectl get deployment
NAME             DESIRED   CURRENT   UP-TO-DATE   AVAILABLE   AGE
my-first-nginx   2         2         2            2           2m

We might also want to create an external IP address for the nginx deployment. On cloud providers that support an external load balancer (such as Google compute engine), using the LoadBalancer type will provision a load balancer for external access. On the other hand, you can still expose the port by creating a Kubernetes service as follows, even though you're not running on platforms that support an external load balancer. We'll describe how to access this externally later:

// expose port 80 for replication controller named my-first-nginx
$ kubectl expose deployment my-first-nginx --port=80 --type=LoadBalancer
service "my-first-nginx" exposed

We can see the service status we just created:

// get all services
$ kubectl get service
NAME             TYPE           CLUSTER-IP      EXTERNAL-IP   PORT(S)        AGE
kubernetes       ClusterIP      10.96.0.1       <none>        443/TCP        2h
my-first-nginx   LoadBalancer   10.102.141.22   <pending>     80:31620/TCP   3m

You may find an additional service named kubernetes if the service daemon run as a container (for example, using kubeadm as a management tool). It is for exposing the REST API of the Kubernetes API server internally. The pending state of my-first-nginx service's external IP indicates that it is waiting for a specific public IP from cloud provider. Take a look at Chapter 6, Building Kubernetes on AWS, and Chapter 7, Building Kubernetes on GCP, for more details.

Congratulations! You just ran your first container with a Kubernetes pod and exposed port 80 with the Kubernetes service.

We can stop the application using commands such as the delete deployment and service. Before this, we suggest you read through the following code first to understand more about how it works:

// stop deployment named my-first-nginx
$ kubectl delete deployment my-first-nginx
deployment.extensions "my-first-nginx" deleted

// stop service named my-first-nginx
$ kubectl delete service my-first-nginx
service "my-first-nginx" deleted
