How-To Tutorials - Game Development

368 Articles
article-image-introduction-hlsl-language
Packt
28 Jun 2013
8 min read
Save for later

Introduction to HLSL language

Packt
28 Jun 2013
8 min read
(For more resources related to this topic, see here.) Distance/Height-based fog Distance/Height-based fog is an approximation to the fog you would normally see outdoors. Even in the clearest of days, you should be able to see some fog far in the distance. The main benefit of adding the fog effect is that it helps the viewer estimate how far different elements in the scene are based on the amount of fog covering them. In addition to the realism this effect adds, it has the additional benefit of hiding the end of the visible range. Without fog to cover the far plane, it becomes easier to notice when far scene elements are clipped by the cameras far plane. By tuning the height of the fog you can also add a darker atmosphere to your scene as demonstrated by the following image: This recipe will demonstrate how distance/height-based fog can be added to our deferred directional light calculation. See the How it works… section for details about adding the effect to other elements of your rendering code. Getting ready We will be passing additional fog specific parameters to the directional light's pixel shader through a new constant buffer. The reason for separating the fog values into their own constant buffer is to allow the same parameters to be used by any other shader that takes fog into account. To create the new constant buffer use the following buffer descriptor: Constant buffer descriptor parameter   Value   Usage   D3D11_USAGE_DYNAMIC   BindFlags   D3D11_BIND_CONSTANT_BUFFER   CPUAccessFlags   D3D11_CPU_ACCESS_WRITE   ByteWidth   48   The reset of the descriptor fields should be set to zero. All the fog calculations will be handled in the deferred directional light pixel shader. How to do it... Our new fog constant buffer is declared in the pixel shader as follows: cbuffer cbFog : register( b2 ){float3 FogColor : packoffset( c0 );float FogStartDepth : packoffset( c0.w );float3 FogHighlightColor : packoffset( c1 );float FogGlobalDensity : packoffset( c1.w );float3 FogSunDir : packoffset( c2 );FogHeightFalloff : packoffset( c2.w );} The helper function used for calculating the fog is as follows: float3 ApplyFog(float3 originalColor, float eyePosY, float3eyeToPixel){float pixelDist = length( eyeToPixel );float3 eyeToPixelNorm = eyeToPixel / pixelDist;// Find the fog staring distance to pixel distancefloat fogDist = max(pixelDist - FogStartDist, 0.0);// Distance based fog intensityfloat fogHeightDensityAtViewer = exp( -FogHeightFalloff * eyePosY );float fogDistInt = fogDist * fogHeightDensityAtViewer;// Height based fog intensityfloat eyeToPixelY = eyeToPixel.y * ( fogDist / pixelDist );float t = FogHeightFalloff * eyeToPixelY;const float thresholdT = 0.01;float fogHeightInt = abs( t ) > thresholdT ?( 1.0 - exp( -t ) ) / t : 1.0;// Combine both factors to get the final factorfloat fogFinalFactor = exp( -FogGlobalDensity * fogDistInt *fogHeightInt );// Find the sun highlight and use it to blend the fog colorfloat sunHighlightFactor = saturate(dot(eyeToPixelNorm, FogSunDir));sunHighlightFactor = pow(sunHighlightFactor, 8.0);float3 fogFinalColor = lerp(FogColor, FogHighlightColor,sunHighlightFactor);return lerp(fogFinalColor, originalColor, fogFinalFactor);} The Applyfog function takes the color without fog along with the camera height and the vector from the camera to the pixel the color belongs to and returns the pixel color with fog. To add fog to the deferred directional light, change the directional entry point to the following code: float4 DirLightPS(VS_OUTPUT In) : SV_TARGET{// Unpack the GBufferfloat2 uv = In.Position.xy;//In.UV.xy;SURFACE_DATA gbd = UnpackGBuffer_Loc(int3(uv, 0));// Convert the data into the material structureMaterial mat;MaterialFromGBuffer(gbd, mat);// Reconstruct the world positionfloat2 cpPos = In.UV.xy * float2(2.0, -2.0) - float2(1.0, -1.0);float3 position = CalcWorldPos(cpPos, gbd.LinearDepth);// Get the AO valuefloat ao = AOTexture.Sample(LinearSampler, In.UV);// Calculate the light contributionfloat4 finalColor;finalColor.xyz = CalcAmbient(mat.normal, mat.diffuseColor.xyz) * ao;finalColor.xyz += CalcDirectional(position, mat);finalColor.w = 1.0;// Apply the fog to the final colorfloat3 eyeToPixel = position - EyePosition;finalColor.xyz = ApplyFog(finalColor.xyz, EyePosition.y,eyeToPixel);return finalColor;} With this change, we apply the fog on top of the lit pixels color and return it to the light accumulation buffer. How it works… Fog is probably the first volumetric effect implemented using a programmable pixel shader as those became commonly supported by GPUs. Originally, fog was implemented in hardware (fixed pipeline) and only took distance into account. As GPUs became more powerful, the hardware distance based fog was replaced by a programmable version that also took into account things such as height and sun effect. In reality, fog is just particles in the air that absorb and reflect light. A ray of light traveling from a position in the scene travels, the camera interacts with the fog particles, and gets changed based on those interactions. The further this ray has to travel before it reaches the camera, the larger the chance is that this ray will get either partially or fully absorbed. In addition to absorption, a ray traveling in a different direction may get reflected towards the camera and add to the intensity of the original ray. Based on the amount of particles in the air and the distance a ray has to travel, the light reaching our camera may contain more reflection and less of the original ray which leads to a homogenous color we perceive as fog. The parameters used in the fog calculation are: FogColor: The fog base color (this color's brightness should match the overall intensity so it won't get blown by the bloom) FogStartDistance: The distance from the camera at which the fog starts to blend in FogHighlightColor: The color used for highlighting pixels with pixel to camera vector that is close to parallel with the camera to sun vector FogGlobalDensity: Density factor for the fog (the higher this is the denser the fog will be) FogSunDir: Normalized sun direction FogHeightFalloff: Height falloff value (the higher this value, the lower is the height at which the fog disappears will be) When tuning the fog values, make sure the ambient colors match the fog. This type of fog is designed for outdoor environments, so you should probably disable it when lighting interiors. You may have noticed that the fog requires the sun direction. We already store the inversed sun direction for the directional light calculation. You can remove that value from the directional light constant buffer and use the fog vector instead to avoid the duplicate values This recipe implements the fog using the exponential function. The reason for using the exponent function is because of its asymptote on the negative side of its graph. Our fog implementation uses that asymptote to blend the fog in from the starting distances. As a reminder, the exponent function graph is as follows: The ApplyFog function starts off by finding the distance our ray traveled in the fog (fogDepth). In order to take the fog's height into account, we also look for the lowest height between the camera and the pixel we apply the fog to which we then use to find how far our ray travels vertically inside the fog (fogHeight). Both distance values are negated and multiplied by the fog density to be used as the exponent. The reason we negate the distance values is because it's more convenient to use the negative side of the exponential functions graph which is limited to the range 0 to 1. As the function equals 1 when the exponent is 0, we have to invert the results (stored in fogFactors). At this point we have one factor for the height which gets larger the further the ray travels vertically into the fog and a factor that gets larger the further the ray travels in the fog in any direction. By multiplying both factors with each other we get the combined fog effect on the ray: the higher the result is, the more the original ray got absorbed and light got reflected towards the camera in its direction (this is stored in fogFinalFactor). Before we can compute the final color value, we need to find the fog's color based on the camera and sun direction. We assume that the sun intensity is high enough to get more of its light rays reflected towards the camera direction and sun direction are close to parallel. We use the dot product between the two to determine the angle and narrow the result by raising it to the power of 8 (the result is stored in sunHighlightFactor). The result is used to lerp between the fog base color and the fog color highlighted by the sun. Finally, we use the fog factor to linearly interpolate between the input color and the fog color. The resulting color is then returned from the helper function and stored into the light accumulation buffer. As you can see, the changes to the directional light entry point are very minor as most of the work is handled inside the helper function ApplyFog. Adding the fog calculation to the rest of the deferred and forward light sources should be pretty straightforward. One thing to take into consideration is that fog also has to be applied to scene elements that don't get lit, like the sky or emissive elements. Again, all you have to do is call ApplyFog to get the final color with the fog effect. Summary In this article, we learned how to apply fog effect and add atmospheric scenes to the images. Resources for Article : Further resources on this subject: Creating and Warping 3D Text with Away3D 3.6 [Article] 3D Vector Drawing and Text with Papervision3D: Part 1 [Article] 3D Vector Drawing and Text with Papervision3D: Part 2 [Article]
Read more
  • 0
  • 0
  • 4572

article-image-introduction-3d-design-using-autocad
Packt
06 Jun 2013
10 min read
Save for later

Introduction to 3D Design using AutoCAD

Packt
06 Jun 2013
10 min read
(For more resources related to this topic, see here.) The Z coordinate 3D is all about the third Z coordinate. In 2D, we only care for the X and Y axes, but never used the Z axis. And most of the time, we don't even use coordinates, just the top-twenty AutoCAD commands, the Ortho tool, and so on. But in 3D, the correct use of coordinates can substantially accelerate our work. We will first briefly cover how to introduce points by coordinates and how to extrapolate to the third dimension. Absolute coordinates The location of all entities in AutoCAD is related to a coordinate system. Any coordinate system is characterized by an origin and positive directions for the X and Y axes. The Z axis is obtained directly from the X and Y axes by the right-hand rule: if we rotate the right hand from the X axis to the Y axis, the thumb indicates the positive Z direction. Picture that when prompting for a point; besides specifying it in the drawing area with a pointing device such as a mouse, we can enter coordinates using the keyboard. The format for the absolute Cartesian coordinates related to the origin is defined by the values of the three orthogonal coordinates, namely, X, Y, and Z, separated by commas: X coordinate, Y coordinate, Z coordinate The Z coordinate can be omitted. For instance, if we define a point with the absolute coordinates 30, 20, and 10, this means 30 absolute is in the X direction, 20 is in the Y direction, and 10 is in the Z direction. Relative coordinates Frequently, we want to specify a point in the coordinates, but one that is related to the previous point. The format for the relative Cartesian coordinates is defined by the symbol AT (@), followed by increment values in the three directions, separated by commas: @X increment, Y increment, Z increment Of course, one or more increments can be 0. The Z increment can be omitted. For instance, if we define a point with relative coordinates, @0,20,10, this means in relation to the previous point, 0 is in X, 20 is in Y, and 10 is in Z directions. Point filters When we want to specify a point but decompose it step-by-step, that is, separate its coordinates based on different locations, we may use filters. When prompting for a point, we access filters by digitizing the X, Y, or Z axes for individual coordinates, or XY, YZ, or ZX for pairs of coordinates. Another way is from the osnap menu, CTRL + mouse right-click, and then Point Filters. AutoCAD requests for the remaining coordinates until the completion of point definition. Imagine that we want to specify a point, for instance, the center of a circle, where its X coordinate is given by the midpoint of an edge, its y coordinate is the midpoint of another edge, and finally its Z coordinate is any point on a top face. Assuming that Midpoint osnap is predefined, the dialog should be: Command: CIRCLESpecify center point for circle or [3P/2P/Ttr (tan tan radius)]: .Xof midpoint of edge(need YZ): .Yof midpoint of edge(need Z): any point on top faceSpecify radius of circle or [Diameter]: value Workspaces AutoCAD comes with several workspaces. It's up to each of us to choose a workspace based on a classic environment or the ribbon. To change workspaces, we can pick the workspace switching button on the status bar: There are other processes for acceding this command such as the workspaces list on the Quick Access Toolbar (title bar), the Workspaces toolbar, or by digitizing WSCURRENT, but the access shown is consistent among all versions and always available. Classic environment The classic environment is based on the toolbars and the menu bar and doesn't use the ribbon. AutoCAD comes with AutoCAD Classic workspace, but it's very simple to adapt and view the suitable toolbars for 3D. The advantages of using this environment are speed and consistency. To show another toolbar, we right-click over any toolbar and choose it. Typically, we want to have the following toolbars visible besides Standard and Layers: Layers II, Modeling, Solid Editing, and Render: Ribbon environment Since the 2009 version, AutoCAD also allows for a ribbon-based environment. Normally, this environment uses neither toolbars nor the menu bar. AutoCAD comes with two ribbon workspaces, namely, 3D Basics and 3D Modeling; the first being less useful than the second. The advantages are that we have consistency with other software, commands are divided into panels and tabs, the ribbon can be collapsed to a single line, and it includes some commands not available on the toolbars. The disadvantage is that as it's a dynamic environment, we frequently have to activate other panels to access commands and some important commands and functions are not always visible: When modeling in 3D, the layers list visibility is almost mandatory. We may add this list to the Quick Access Toolbar by applying the CUI command or by right-clicking above the command icon we want to add. Another way is to pull the Layers panel to the drawing area, thus making it permanently visible. Layers, transparency, and other properties When we are modeling in AutoCAD, the ability to control object properties is essential. After some hours spent on a new 3D model, we can have hundreds of objects that overlap and obscure the model's visibility. Here are the most important properties. Layers If a correct layers application is fundamental in 2D, in 3D it assumes extreme importance. Each type of 3D object should be in a proper layer, thus allowing us to control its properties: Name: A good piece of advice is to not mix 2D with 3D objects in the same layers. So, layers for 3D objects must be easily identified, for instance, by adding a 3D prefix. Freeze/Thaw: In 3D, the density of screen information can be huge. So freezing and unfreezing layers is a permanent process. It's better to freeze the layers than to turn off because objects on frozen layers are not processed (for instance, regenerating or counting for ZOOM Extents), thus accelerating the 3D process. Lock/Unlock: It's quite annoying to notice that at an advanced phase of our project, our walls moved and caused several errors. If we need that information visible, the best way to avoid these errors is to lock layers. Color: A good and logical color palette assigned to our layers can improve our understanding while modeling. Transparency: If we want to see through walls or other objects at the creation process, we may give a value between 0 and 90 percent to the layers transparency. Last but not least, the best and the easiest process to assign rendering materials to objects is by layer, so another good point is to apply a correct and detailed layer scheme. Transparency Transparency, as a property for layers or for objects, has been available since Version 2011. Besides its utility for layers, it can also be applied directly to objects. For instance, we may have a layer called 3D-SLAB and just want to see through the upper slab. We can change the objects' transparency with PROPERTIES (Ctrl + 1). To see transparencies in the drawing area, the TPY button (on the status bar) must be on. Visibility Another recent improvement in AutoCAD is the ability to hide or to isolate objects without changing layer properties. We select the objects to hide or to isolate (all objects not selected are hidden) and right-click on them. On the cursor menu, we choose Isolate and then: Isolate Objects: All objects not selected are invisible, using the ISOLATEOBJECTS command Hide Objects: The selected objects are invisible, using the HIDEOBJECTS command End Object Isolation: All objects are turned on, using the UNISOLATEOBJECTS command. There is a small lamp icon on the status bar, the second icon from the right. If the lamp is red, it means that there are hidden objects; if it is yellow, all objects are visible: Shown on the following image is the application of transparency and hide objects to the left wall and the upper slab: Auxiliary tools AutoCAD software is very precise and the correct application of these auxiliary tools is a key factor for good projects. All users should be familiar with at least Ortho and Osnap tools. Following is the application of auxiliary tools in 3D projects complemented with the first exercise. OSNAP, ORTHO, POLAR, and OTRACK auxiliary tools Let's start with object snapping, probably the most frequently used tool for precision. Every time AutoCAD prompts for a point, we can access predefined object snaps (also known as osnaps) if the OSNAP button on the status bar is on. To change it, we only have to click on the OSNAP button or press F3. If we want an individual osnap, we can, among other ways, digitize the first three letters (for instance, MID for midpoint) or use the osnap menu (CTRL + right-click). Osnaps work everywhere in 3D (which is great) and is especially useful is the Extension osnap mode, which allows you to specify a point with a distance in the direction of any edge. But what if we want to specify the projection of 3D points onto the working XY plane? Easy! If the OSNAPZ variable is set to 1, all specified points are projected onto the plane. This variable is not saved and 0 is assigned as the initial value. More great news is that ORTHO (F8) and POLAR (F10) work in 3D. That is, we can specify points by directing the cursor along the Z axis and assign distances. Lots of @ spared, no? OTRACK (F11), used to derive points from predefined osnaps, also works along the Z-axis direction. We pause over an osnap and can assign a distance along a specific direction or just obtain a crossing: 3DOsnap tool Starting with Version 2011, AutoCAD allows you to specify 3D object snaps. Also, here we can access predefined 3D osnaps keeping 3DOSNAP (F4) on, or we can access them individually. There are osnaps for vertices, midpoints on edges, centers of faces, knots (spline points), points perpendicular to faces, and points nearest to faces. Exercise 1.1 Using the LINE command, coordinates, and auxiliary tools, let's create a cabinet skeleton. All dimensions are in meters and we start from the lower-left corner. The ORTHO or POLAR button must be on and the OTRACK and OSNAP buttons with Endpoint and Midpoint predefined. As in 2D, rotating the wheel mouse forward, we zoom in; rotating the wheel backward, we zoom out; all related to cursor position. To automatically orbit around the model, we hold down SHIFT and the wheel simultaneously. The cursor changes to two small ellipses and then we drag the mouse to orbit around the model. Visualization is the subject of the next article We run the LINE command at any point, block direction X (POLAR or ORTHO) and assign the distance: Command: LINESpecify first point: any pointSpecify next point or [Undo]: 0.6 We block the Z direction and assign the distance: Specify next point or [Undo]: 0.7 The best way to specify this point is with relative coordinates: Specify next point or [Close/Undo]: @-0.3,0,0.4 We block the Z direction and assign the distance: Specify next point or [Close/Undo]: 0.7 The best way to close the left polygon is to pause over the first point, move the cursor up to find the crossing, with Polar or Ortho coming from the last point, and apply Close option to close the polygon: Specify next point or [Close/Undo]: point with OTRACKSpecify next point or [Close/Undo]: C We copy all lines 1 meter in the Y direction: Command: COPYSelect objects: Specify opposite corner: 6 foundSelect objects: EnterCurrent settings: Copy mode = MultipleSpecify base point or [Displacement/mOde] <Displacement>: pointSpecify second point or [Array] <use first point as displacement>:1Specify second point or [Array/Exit/Undo] <Exit>: Enter We complete the cabinet skeleton by drawing lines between endpoints Command: LINE
Read more
  • 0
  • 0
  • 4215

article-image-article-playing-particles
Packt
06 Jun 2013
19 min read
Save for later

Playing with Particles

Packt
06 Jun 2013
19 min read
(For more resources related to this topic, see here.) Introducing particle effects Particle effects are the decorative flourishes used in games to represent dynamic and complex phenomena, such as fire, smoke, and rain. To create a particle effect, it requires three elements: a System, Emitters, and the Particles themselves. Understanding particle systems Particle systems are the universe in which the particles and emitters live. Much like the universe, we cannot define the size but we can define a point of origin which all emitters and particles will be placed relative to. We can also have multiple particle systems in existence at any given time, which can be set to draw the particles at different depths. While we can have as many particle systems as we want, it is best to have as few as possible in order to prevent possible memory leaks. The reason for this is that once a particle system is created, it will remain in existence forever unless it is manually destroyed. Destroying the instance that spawned it or changing rooms will not remove the system, so make sure it is removed when it is no longer needed. By destroying a particle system, it will remove all the emitters and particles in that system along with it. Utilizing particle emitters Particle emitters are defined areas within a system from which particles will spawn. There are two types of emitters to choose from: Burst emitters that spawn particles a single time, and Stream emitters that spew particles continuously over time. We can define the size and shape of the region in space for each emitter, as well as how the particles should be distributed within the region. Image When defining the region in space, there are four Shape options: DIAMOND, ELLIPSE, LINE, and RECTANGLE. An example of each can be seen in the preceding diagram, all using exactly the same dimensions, amount of particles, and distribution. While there is no functional difference between using any one of these shapes, the effect itself can benefit from a properly chosen shape. For example, only a LINE can make an effect appear to be angled 30 degrees. Image The distribution of the particles can also affect how the particles are expelled from the emitter. As can be seen in the preceding diagram, there are three different distributions. LINEAR will spawn particles with an equal random distribution throughout the emitter region. GAUSSIAN will spawn particles more towards the center of the region. INVGAUSSIAN is the inverse of GAUSSIAN, wherein the particles will spawn closer to the edges of the emitter. Applying particles Particles are the graphic resources that are spawned from the emitters. There are two types of particles that can be created: Shapes and Sprites. Shapes are the collection of 64 x 64 pixel sprites that comes built-in with GameMaker: Studio for use as particles. The shapes, as seen in the next diagram, are suitable for the majority of the most common effects, such as fireworks and flames. When wanting to create something more specialized for a game, we can use any Sprite in the Resource tree. Image There are a lot of things we can do with particles by adjusting the many attributes available. We can define ranges for how long it lives, the color it should be, and how it moves. We can even spawn more particles at the point of death for each particle. There are, however, some things that we cannot do. In order to keep the graphics processing costs low, there is no ability to manipulate individual particles within an effect. Also, particles cannot interact with objects in any way, so there is no way to know if a particle has collided with an instance in the world. If we need this kind of control, we need to build objects instead. Designing the look of a particle event is generally a trial and error process that can take a very long time. To speed things up, try using one of the many particle effect generators available on the Internet, such as Particle Designer 2.5 by Alert Games found here: http://alertgames.net/index.php?page=s/pd2. HTML5 limitations Using particle effects can really improve the visual quality of a game, but when developing a game intended to be played in a browser we need to be careful. Before implementing a particle effect, it is important to understand potential problems we may encounter. The biggest issue surrounding particles is that in order for them to be rendered smoothly without any lag, they need to be rendered with the graphics processor instead of the main CPU. Most browsers allow this to happen through a JavaScript API called WebGL. It is not, however, an HTML5 standard and Microsoft has stated that they have no plans for Internet Explorer to support it for the foreseeable future. This means a potentially significant portion of the game's potential audience could suffer poor gameplay if particles are used. Additionally, even with WebGL enabled, the functionality for particles to have additive blending and advanced color blending cannot be used, as none of the browsers currently support this feature. Now that we know this we are ready to make some effects! Adding particle effects to the game We are going to build a few different particle effects to demonstrate the various ways effects can be implemented in a game, and to look into some of the issues that might arise. To keep things straightforward, all of the effects we create will be a part of a single, global particle system. We will use both types of emitters, and utilize both shape and sprite-based particles. We will start with a Dust Cloud that will be seen anytime a Pillar is broken or destroyed. We will then add a system to create a unique shrapnel effect for each Pillar type. Finally, we will create some fire and smoke effects for the TNT explosion to demonstrate moving emitters. Creating a Dust Cloud The first effect we are going to create is a simple Dust Cloud. It will burst outwards upon the destruction of each Pillar and dissolve away over time. As this effect will be used in every level of the game, we will make all of its elements global, so they only need to be declared once. Open the Tower Toppling project we were previously working on if it is not already open. We need to make sure that WebGL is enabled when we build the game. Navigate to Resources | Change Global Game Settings and click on the HTML5 tab. On the left-hand side, click on the tab for Graphics. As seen in the following screenshot, there are three options under WebGL in Options. If WebGL is Disabled, the game will not be able to use the GPU and all browsers will suffer from any potential lag. If WebGL is Required, any browser that does not have this capability will be prevented from running the game. The final option is Auto-Detect which will use WebGL if the browser supports it, but will allow all browsers to play the game no matter what. Select Auto-Detect and then click on OK. Image Now that we have WebGL activated we can build our effects. We will start by defining our particle system as a global variable by creating a new script called scr_Global_Particles. code The first effect we are going to make is the Dust Cloud which will be attached to the Pillars. For this we only need a single emitter which we will move to the appropriate position when it is needed. Create a global variable for the emitter and add it to the particle system with the following code at the end of the script: code For this particle, we are going to use one of the built-in shapes, pt_shape_explosion, which looks like a little thick cloud of dust. Add the following code to the end of the script: code Once again we have made this a global variable, so that we have to create this Dust Cloud particle only once. We have declared only the shape attribute of this particle at this time. We will add more to this later once we can see what the effect looks like in the game. We need to initialize the particle system with the other global variables. Reopen scr_Global_GameStart and call the particles script. code With everything initialized, we can now create a new script, scr_Particles_DustCloud, which we can use to set the region of the emitter and have it activate a burst of particles. code We start by defining a small area for the emitter based on the position of instance that calls this script. The region itself will be circular with a Gaussian distribution so that the particles shoot out from the center. We then activate a single burst of 10 dust particles from the emitter. All we need to do now is execute this script from the destruction of a Pillar. Reopen scr_Pillar_Destroyand insert the following line of code on the line before the instance is destroyed: code We need to add this effect to the breaking of the Pillars as well. Reopen scr_ Pillar_BreakApart and insert the same code in the same spot. Save the game and then play it. When the glass Pillars are destroyed, we should see thick white clouds appearing as shown in the following screenshot: Image The particles are boring and static at this point, because we have not told the particles to do anything other than to look like the shape of a cloud. Let's fix this by adding some attributes to the particle. Reopen scr_Global_Particles and add the following code at the end of the script: code The first attribute we add is how long we want the particle to live for, which is a range between 15 and 30 steps, or at the speed of our rooms, a half to a whole second. Next, we want the particles to explode outwards, so we set the angle and add some velocity. Both functions that we are using have similar parameters. The first value is the particle type for which this is to be applied. The next two parameters are the minimum and maximum values from which a number will be randomly chosen. The fourth parameter sets an incremental value every step. Finally, the last parameter is a wiggle value that will randomly be applied throughout the particle's lifetime. For the Dust Cloud, we are setting the direction to be in any angle and the speed is fairly slow, ranging only a few pixels per step. We also want to change the size of the particles and their transparency, so that the dust appears to dissipate. Save the game and run it again. This time the effect appears much more natural, with the clouds exploding outwards, growing slightly larger, and fading out. It should look something like the next screenshot. The Dust Cloud is now complete. Image Adding in Shrapnel The Dust Cloud effect helps the Pillar destruction appear more believable, but it lacks the bigger chunks of material one would expect to see. We want some Shrapnel of various shapes and sizes to explode outwards for each of the different types of Pillars. We will start with the Glass particles. Create a new Sprite, spr_Particle_Glass, and with Remove Background checked, load Chapter 8/Sprites/Particle_Glass.gif.mhanaje This sprite is not meant to be animated, though it does have several frames within it. Each frame represents a different shape of particle that will be randomly chosen when the particle is spawned. We will want the particles to rotate as they move outwards, so we need to center the origin. Click on OK. Reopen scr_Global_Particles and initialize the Glass particle at the end of the script. code Once we have created the global variable and the particle, we set the particle type to be a Sprite. When assigning Sprites there are a few extra parameters beyond which resources should be used. The third and fourth parameters are for whether it should be animated, and if so, should the animation stretch for the duration of the particle's life. In our case we are not using animation, so it has been set to false. The last parameter is for whether we want it to choose a random subimage of the Sprite, which is what we do want it to do. We also need to add some attributes to this particle for life and movement. Add the following code at the end of the script: code When compared with the Dust Cloud, this particle will have a shorter lifespan but will move at a much higher velocity. This will make this effect more intense while keeping the general area small. We have also added some rotational movement through part_type_orientation. The particles can be set to any angle and will rotate 20 degrees per frame with a variance of up to four degrees. This will give us a nice variety in the spin of each particle. There is one additional parameter for orientation, which is whether the angle should be relative to its movement. We have set it to false as we just want the particles to spin freely. To test this effect out, open up scr_Particles_DustCloud and insert a burst emitter before the Dust Cloud is emitted, so that the Glass particles appear behind the other effect. code Save the game and then play it. When the Pillars break apart, there should be shards of Glass exploding out along with the Dust Cloud. The effect should look something like the following screenshot: Image Next we need to create Shrapnel for the Wood and Steel particles. Create new Sprites for spr_Particle_Wood and spr_Particle_Steel with the supplied images in Chapter 8/Sprites/ in the same manner as we did for Glass. As these particles are global, we cannot just swap the Sprite out dynamically. We need to create new particles for each type. In scr_Global_Particles, add particles for both Wood and Steel with the same attributes as Glass. Currently the effect is set to Always create Glass particles, something we do not want to do. To fix this we are going to add a variable, myParticle, to each of the different Pillars to allow us to spawn the appropriate particle. Open scr_Pillar_Glass_Create and add the following code at the end of the script: code Repeat the last step for Wood and Steel with the appropriate particle assigned. In order to have the proper particle spawn, all we need to do is reopen scr_Particles_DustCloud and change the variable particle_Glass to myParticle as in the following code: code Save the game and play the game until you can destroy all the three types of Pillars to see the effect. It should look something similar to the following screenshot, where each Pillar spawns its own Shrapnel: Image Making the TNT explosion When the TNT explodes, it shoots out some TNT Fragments which are currently bland looking Sprites. We want the Fragments to be on fire as they streak across the scene. We also want a cloud of smoke to rise up from the explosion to indicate that the explosion we see is actually on fire. This is going to cause some complications. In order to make something appear to be on fire, it will need to change color, say from white to yellow to orange. As we have already mentioned, due to the fact that WebGL is not supported by all browsers, we cannot utilize any of the functions that allow us to blend colors together. This means that we need to work around this issue. The solution is to use several particles instead of one. We will start by creating some custom colors so that we can achieve the look of fire and smoke that we want. Open scr_Global_Colors and add the following colors: code We already have a nice yellow color, so we add an orange, a slightly yellow tinted white, and a partially orange black color. In order to achieve the fake blending effect we will need to spawn one particle type, and upon its death, have it spawn the next particle type. For this to work properly, we need to construct the creation of the particles in the opposite order that they will be seen. In this case, we need to start by building the smoke particle. In scr_Global_Particles add a new particle for the smoke with the following attributes: code We start by adding the particle and using the built-in smoke shape. We want the smoke to linger for a while, so we set its life to range between a minimum of a second to almost two full seconds. We then set the direction and speed to be more or less upwards so that the smoke rises. Next, we set the size and have it grow over time. With the alpha values, we don't want the smoke to be completely opaque, so we set it to start at half transparent and fade away over time. Next, we are using part_type_color1 which allows us to tint the particle without affecting the performance very much. Finally, we apply some gravity to the particles so that any angled particles float slowly upwards. The smoke is the final step of our effect and it will be spawned from an orange flame that precedes it. code Once again we set up the particle using the built-in smoke shape, this time with a much shorter lifespan. The general direction is still mainly upwards, though there is more spread than the smoke. These particles are slightly smaller, tinted orange and will be partially transparent for its entire life. We have added a little bit of upward gravity, as this particle is in between fire and smoke. Finally, we are using a function that will spawn a single particle of smoke upon the death of each orange particle. The next particle in the chain for this effect is a yellow particle. This time we are going to use the FLARE shape, which will give a better appearance of fire. It will also be a bit smaller, live slightly longer than the orange particle, and move faster, spreading in all directions. We will not add any transparency to this particle so that it appears to burn bright. code We have only one more particle to create this effect for, which is the hottest and brightest white particle. Its construction is the same as the yellow particle, except it is smaller and faster. code We now have all the particles we need for this particle effect; we just need to add an emitter to spawn them. This time we are going to use a stream emitter, so that the fire continuously flows out of each Fragment. Since the Fragments are moving, we will need to have a unique emitter for each Fragment we create. This means it cannot be a global emitter, but rather a local one. Open scr_TNT_Fragment_Create and add the following code at the end of the script: code We create an emitter with a fairly small area for spawning with balanced distribution. At every step, the emitter will create five new Fire particles as long as the emitter exists. The emitter is now created at the same time as the Fragment, but we need the emitter to move along with it. Open scr_TNT_Fragment_Step and add the following code: code As already mentioned we need to destroy the emitter, otherwise it will never stop streaming particles. For this we will need to open obj_TNT_Fragment and add a destroy event with a new Script, scr_TNT_Fragment_Destroy, which removes the emitter attached. code This function will remove the emitter from the system without removing any of the particles that had been spawned. One last thing we need to do is to uncheck the Visible checkbox, as we don't want to see the Fragment sprite, but just the particles. Save the game and detonate the TNT. Instead of just seeing a few Fragments, there are now streaks of fire jetting out of the explosion that turn into dark clouds of smoke that float up. It should look something like the following screenshot: Image Cleaning up the particles At this point, we have built a good variety of effects using various particles and emitters. The effects have added a lot of polish to the game, but there is a flaw with the particles. If the player decides to restart the room or go to the SHOP immediately after the explosion has occurred, the emitters will not be destroyed. This means that they will continue to spawn particles forever, and we will lose all references to those emitters. The game will end up looking like the following screenshot: Image The first thing we need to do is to destroy the emitters when we leave the room. Luckily, we have already written a script that does exactly this. Open obj_TNT_Fragment and add a Room End event and attach scr_TNT_Fragment_Destroy to it. Even if we destroy the emitters before changing rooms, any particles remaining in the game will still appear in the next room, if only briefly. What we need to do is clear all the particles from the system. While this might sound like it could be a lot of work, it is actually quite simple. As Overlord is in every level, but not in any other room, we can use it to clean up the scene. Open obj_Overlord, add a Room End event and attach a new Script, scr_Overlord_RoomEnd, with the following line of code: part_particles_clear(system); This function will remove any particle that exists within the system, but will not remove the particle type from memory. It is important that we do not destroy the particle type, as we would not be able to use a particle again if its type no longer exists. Save the game, explode some TNT, and restart the room immediately. You should no longer see any particles in the scene. Summary In this article, we were provided with the details to add some spit and polish to the game to really make it shine. We delved into the world of particles and created a variety of effects that add impact to the TNT and Pillar destruction. Resources for Article : Further resources on this subject: HTML5: Generic Containers [Article] HTML5 Presentations - creating our initial presentation [Article] Deploying HTML5 Applications with GNOME [Article]
Read more
  • 0
  • 0
  • 2835
Visually different images

article-image-creating-our-first-game
Packt
31 May 2013
11 min read
Save for later

Creating Our First Game

Packt
31 May 2013
11 min read
(For more resources related to this topic, see here.) Let's get serious – the game The game we will implement now is inspired by Frogger. In this old school arcade game, you played the role of a frog trying to cross the screen by jumping on logs and avoiding cars. In our version, the player is a developer who has to cross the network cable by jumping packets and then cross the browser "road" by avoiding bugs. To sum up, the game specifications are as follows: If the player presses the up arrow key once, the "frog" will go forward one step. By pressing the right and left arrow key, the player can move horizontally. In the first part (the network cable) the player has to jump on packets coming from the left of the screen and moving to the right. The packets are organized in lines where packets of each line travel at different speeds. Once the player is on a packet, he/she will move along with it. If a packet drives the player outside of the screen, or if the player jumps on the cable without reaching a packet, he/she will die and start at the beginning of the same level once again. In the second part (the browser part) the player has to cross the browser screen by avoiding the bugs coming from the left. If the player gets hit by a bug he/she will start at the beginning of the same level once again. These are very simple rules, but as you will see they will already give us plenty of things to think about. Learning the basics Throughout this article, we will use DOM elements to render game elements. Another popular solution would be to use the Canvas element. There are plus and minus points for both technologies and there are a few effects that are simply not possible to produce with only DOM elements. However, for the beginner, the DOM offers the advantage of being easier to debug, to work on almost all existing browsers (yes, even on Internet Explorer 6), and in most cases to offer reasonable speed for games. The DOM also abstracts the dirty business of having to target individual pixels and tracking which part of the screen has to be redrawn. Even though Internet Explorer supports most of the features we will see in this book, I would not recommend creating a game that supports it. Indeed, its market share is negligible nowadays (http://www.ie6countdown.com/) and you will encounter some performance issues. Now from some game terminology, sprites are the moving part of a game. They may be animated or nonanimated (in the sense of changing their aspect versus simply moving around). Other parts of the game may include the background, the UI, and tiles. Framework During this article, we will write some code; part of the code belongs to an example game and is used to describe scenes or logic that are specific to it. Some code, however, is very likely to be reused in each of your games. For this reason, we will regroup some of those functions into a framework that we will cleverly call gameFramework or gf in short. A very simple way to define a namespace in JavaScript is to create an object and add all your function directly to it. The following code gives you an example of what this might look like for two functions, shake and stir, in the namespace cocktail. // define the namespacevar cocktail = {};// add the function shake to the namespacecocktail.shake = function(){...}// add the function stir to the namespacecocktail.stir = function(){...} This has the advantage of avoiding collision with other libraries that use similar names for their objects or functions. Therefore, from now on when you see any function added to the namespace, it will mean that we think those functions will be used by the other games we will create later in this article or that you might want to create yourself. The following code is another notation for namespace. Which one you use is a personal preference and you should really use the one that feels right to you! var cocktail = {// add the function shake to the namespaceshake: function(){...},// add the function stir to the namespacestir: function(){...}}; Typically, you would keep the code of the framework in a JS file (let's say gameFramework.js) and the code of the game in another JS file. Once your game is ready to be published, you may want to regroup all your JavaScript code into one file (including jQuery if you wish so) and minimize it. However, for the whole development phase it will be way more convenient to keep them separate. Sprites Sprites are the basic building blocks of your game. They are basically images that can be animated and moved around the screen. To create them you can use any image editor. If you work on OS X, there is a free one that I find has been particularly well done, Pixen (http://pixenapp.com/). You can use animated gifs. With this method you have no way to access the index of the current frame through JavaScript, and no control over when the animation starts to play or when it ends. Furthermore, having many animated GIFs tends to slow things down a lot. You can change the source of the image. This is already a better solution, but provides worse performance if proposed and requires a large number of individual images. Another disadvantage is that you cannot choose to display only one part of the image; you have to show the entire image each time. Finally, if you want to have a sprite made of a repeating image, you will have to use many img elements. For the sake of completeness, we should mention here one advantage of img; it's really easy to scale an img element—just adjust the width and height. The proposed solution uses simple divs of defined dimensions and sets an image in the background. To generate animated sprites, you could change the background image, but instead we use the background position CSS property. The image used in this situation is called a sprite sheet and typically looks something like the following screenshot: The mechanism by which the animation is generated is shown in the following screenshot: Another advantage is that you can use a single sprite sheet to hold multiple animations. This way you will avoid having to load many different images. Depending on the situation, you may still want to use more than one sprite sheet, but it's a good thing to try to minimize their number. Implementing animations It's very simple to implement this solution. We will use .css() to change the background properties and a simple setInterval to change the current frame of the animation. Therefore, let's say that we have a sprite sheet containing 4 frames of a walk cycle where each frame measures 64 by 64 pixels. First, we simply have to create a div with the sprite sheet as its background. This div should measure 64 by 64 pixels, otherwise the next frame would leak onto the current one. In the following example, we add the sprite to a div with the ID mygame. $("#mygame").append("<div id='sprite1'>"); $("#sprite1").css("backgroundImage","url('spritesheet1.png')"); As the background image is by default aligned with the upper-left corner of the div, we will only see the first frame of the walk-cycle sprite sheet. What we want is to be able to change what frame is visible. The following function changes the background position to the correct position based on the argument passed to it. Take a look at the following code for the exact meaning of the arguments: /** * This function sets the current frame. * -divId: the Id of the div from which you want to change the * frame * -frameNumber: the frame number * -frameDimension: the width of a frame **/ gameFramework.setFrame = function(divId,frameNumber, frameDimension) { $("#"+divId) .css("bakgroundPosition", "" + frameNumber * frameDimension + "px 0px"); } Now we have to call this at regular intervals to produce the animation. We will use setInterval with an interval of 60 milliseconds, that is, around 17 frames per second. This should be enough to give the impression of walking; however, this really has to be fine-tuned to match your sprite sheet. To do this we use an anonymous function that we pass to setInterval, which will in turn call our function with the correct parameter. var totalNumberOfFrame = 4;var frameNumber = 0;setInterval(function(){gameFramework.setFrame("sprite1",frameNumber, 64);frameNumber = (frameNumber + 1) % totalNumberOfFrame;}, 60); You probably noticed that we're doing something special to compute the current frame. The goal is to cover values from 0 to 3 (as they're 4 frames) and to loop back to 0 when we reach 4. The operation we use for this is called modulo (%) and it's the rest of the integer division (also known as Euclidean division). For example, at the third frame we have 3 / 4 which is equal to 0 plus a remainder of 3, so 3 % 4 = 3. When the frame number reaches 4 we have 4 / 4 = 1 plus a remainder of 0, so 4 % 4 = 0. This mechanism is used in a lot of situations. Adding animations to our framework As you can see there are more and more variables needed to generate an animation: the URL of the image, the number of frames, their dimension, the rate of the animation, and the current frame. Furthermore, all those variables are associated with one animation, so if we need a second one we have to define twice as many variables. The obvious solution is to use objects. We will create an animation object that will hold all the variables we need (for now, it won't need any method). This object, like all the things belonging to our framework, will be in the gameFramework namespace. Instead of giving all the values of each of the properties of the animation as an argument, we will use a single object literal, and all the properties that aren't defined will default to some well-thought-out values. To do this, jQuery offers a very convenient method: $.extend. This is a very powerful method and you should really take a look at the API documentation (http://api.jquery.com/) to see everything that it can do. Here we will pass to it three arguments: the first one will be extended with the values of the second one and the resulting object will be extended with the values of the third. /*** Animation Object.**/gf.animation = function(options) {var defaultValues = {url : false,width : 64,numberOfFrames : 1,currentFrame : 0,rate : 30};$.extend(this, defaultValues, options);} To use this function we will simply create a new instance of it with the desired values. Here you can see the values used in the preceding examples: var firstAnim = new gameFramework.animation({url: "spritesheet1.png",numberOfFrames: 4,rate: 60}); As you can see, we didn't need to specify width: 64 because it's the default value! This pattern is very convenient and you should keep it in mind each time you need default values and also the flexibility to override them. We can rewrite the function to use the animation object: gf.setFrame = function(divId, animation) {$("#" + divId).css("bakgroundPosition", "" + animation.currentFrame *animation.width + "px 0px");} Now we will create a function for our framework based on the technique we've already seen, but this time it will use the new animation object. This function will start animating a sprite, either once or in a loop. There is one thing we have to be careful about—if we define an animation for a sprite that is already animated we need to deactivate the current animation and replace it with the new one. To do this we will need an array to hold the list of all intervals' handles. Then we'll only need to check if one exists for this sprite and clear it, then define it again. gf.animationHandles = {}; /** * Sets the animation for the given sprite. **/ gf.setAnimation = function(divId, animation, loop){ if(gf.animationHandles[divId]){ clearInterval(gf.animationHandles[divId]); } if(animation.url){ $("#"+divId).css("backgroundImage","url('"+animation. url+"')"); } if(animation.numberOfFrame > 1){ gf.animationHandles[divId] = setInterval(function(){ animation.currentFrame++; if(!loop && currentFrame > animation.numberOfFrame){ clearInterval(gf.animationHandles[divId]); gf.animationHandles[divId] = false; } else { animation.currentFrame %= animation. numberOfFrame; gf.setFrame(divId, animation); } }, animation.rate); } } This will provide a convenient, flexible, and quite high-level way to set an animation for a sprite.
Read more
  • 0
  • 0
  • 2325

article-image-article-making-money-your-game
Packt
17 May 2013
23 min read
Save for later

Making Money with Your Game

Packt
17 May 2013
23 min read
(For more resources related to this topic, see here.) Your game development strategy If you want to build a game to make some money, it is imperative you take a few things into consideration before starting off building one. The first question you will need to ask yourself is probably this: who am I going to build a game for? Are you aiming at everyone capable of playing games or do you want to target a very specific segment of people and meet their gaming needs? This is the difference between broad and niche targeting. An example of very broadly targeted games are most tower defense games, in which you need to build towers with diverse properties to repel an army. Games such as Tetris, Bejeweled, Minesweeper, and most light puzzle games in general. Angry Birds is another example of a game that is popular with a broad audience because of its simplicity, likeable graphics, and incredible amount of clever marketing. Casual games in general seem to appeal to the masses because of the following few factors: Simplicity prevails: most gamers get used to the game in mere minutes. There are little or no knowledge prerequisites: you are not expected to already know some of the background story or have experience in these types of games. Casual gamers tend to do well even though they put in less time to practice. Even if you do well from the start, you can still become better at it. A game at which you cannot become better by replaying doesn't hold up for long. Notable exceptions are games of chance like roulette and the slots, which do prove to be addictive; but that is for other reasons, such as the chance to win money. The main advantage to building casual games is that practically everyone is a potential user of your game. As such, the achievable success can be enormous. World of Warcraft is a game which has moved from rather hardcore and niche to more casual over the years. They did this because they had already reached most regular gamers out there, and decided to convince the masses that you can play World of Warcraft even if you don't play a lot in general. The downside of trying to please everyone is the amount of competition. Sticking out as a unique game among numerous games out there is tremendously difficult. This is especially true if you don't have an impressive marketing machine to back it up. A good example of a niche game is any game built after a movie. Games on Star Trek, Star Wars, Lord of the Rings, and so on, are mostly aimed at people who have seen and liked those movies. Niche games can also be niche because they are targeted solely at a specific group of gamers. For example, people who prefer playing FPS (First Person Shooters) games, and do so every single day. In essence, niche games have the following properties (note that they oppose casual or broadly targeted games): Steep learning curve: mastery requires many hours of dedicated gaming. Some knowledge or experience with games is required. An online shooter game such as PlanetSide 2 requires you to have at least some experience with shooter games in the past, since you are pitted against people who know what they are doing. The more you play the game, the more are the useful rewards you get. Playing a lot is often rewarded with items that make you even stronger in the game, thus reinforcing the fact that you already became better by playing more. StarCraft is a game released by Blizzard in 1998 and is still being played in tournaments today, even though there is a follow up: StarCraft 2. Games such as the original StarCraft are perfectly feasible to be built in HTML5 and run on a browser or smartphone. When StarCraft was released, the average desktop computer had less power than many smartphones have today. Technically, the road is open; replicating the same level of success is another matter though. The advantage of aiming at a niche of gamers is the unique position you can take in their lives. Maybe there are not many people in your target group, but it will be easier to get and keep their attention with your game since it is specifically built for them. In addition, it doesn't mean that because you have a well-defined aim, gamers can't drop in from unexpected corners. People you would have never thought would play your game can still like what you did. It is for this reason that knowing your gamers is so important, and why tools such as Playtomic exist. The disadvantage of the niche marketing is obvious: your game is very unlikely to grow beyond a certain point; it will probably never rank among the most played games in the world. The type of games you are going to develop is one choice, the amount of detail you put in each one of them is another. You can put as much effort into building a single game as you want. In essence, a game is never finished. A game can always have an extra level, Easter egg, or another nice little detail. When scoping your game, you must have decided whether you will use a shotgun or a sniper development strategy. In a shotgun strategy, you develop and release games quickly. Each game still has a unique element that should distinguish it from other games: the UGP (Unique Gaming Proposition). But games released under a shotgun strategy don't deliver a lot of details; they are not polished. The advantages of adopting a shotgun strategy are plenty: Low development cost; thus every game represents a low risk The short time to market allows for using world events as game settings You have several games on the market at once, but often you only need a single one to succeed in order to cover the expenses incurred for the others Short games can be given to the public for free but monetized by selling add-ons, such as levels However, it's not just rainbows and sunshine when you adopt this strategy. There are several reasons why you wouldn't choose shotgun strategy: A game that doesn't feel finished has less chance of being successful than a perfected one. Throwing your game on the market not only tests whether a certain concept works, but also exposes it to the competitors, who can now start building a copy. Of course, you have the first mover advantage, but it's not as big as it could have been. You must always be careful not to throw garbage on the market either, or you might ruin your name as a developer. However, don't get confused. The shotgun strategy is not an excuse for building mediocre games. Every game you release should have an original touch to it— something that no other game has. If a game doesn't have that new flavor, why would anyone prefer it over all the others? Then, of course, there is the sniper strategy, which involves building a decent and well-thought-out game and releasing it to the market with the utmost care and support. This is what distributors such as Apple urge developers to do, and for good reason—you wouldn't want your app store full of crappy games, would you? Some other game distributers, such as Steam, are even pickier in the games they allow to be distributed, making the shotgun strategy nearly impossible. But it is also the strategy most successful game developers use. Take a look at developers such as Rockstar (developer of the GTA series), Besthesda (developer of the Elder Scroll series), Bioware (developer of the Mass Effect series), Blizzard (developer of the Warcraft series), and many others. These are no small fries, yet they don't have that many games on the market. This tactic of developing high quality games and hoping they will pay off is obviously not without risk. In order to develop a truly amazing game, you also need the time and money to do so. If your game fails to sell, this can be a real problem for you or your company. Even for HTML5 games, this can be the case, especially since devices and browsers keep getting more and more powerful. When the machines running the games get more powerful, the games themselves often become more complex and take longer to develop. We have taken a look at two important choices one needs to make when going into the game-developing business. Let's now look at the distribution channels that allow you to make money with your game, but before that let's summarize the topic we have just covered: Deciding who you want to target is extremely important even before you start developing your game. Broad targeting is barely targeting at all. It is about making a game accessible and likeable by as many people as possible. Niche targeting is taking a deeper look and interest in a certain group of people and building a game to suit their specific gaming needs. In developing and releasing games, there are two big strategies: shotgun and sniper. In the shotgun strategy you release games rapidly. Each game still has unique elements that no other games possess, but they are not as elaborate or polished as they could be. With the sniper strategy you build only a few games, but each one is already perfected at the time of release and only needs slight polishing when patches are released for it. Making money with game apps If you built your game into an app, you have several distribution channels you can turn to, such as Firefox marketplace, the IntelAppUp center, Windows Phone Store, Amazon Appstore, SlideMe, Mobango, Getjar, and Apple Appsfire. But the most popular players on the market currently are Google Play and the iOS App Store. The iOS App Store is not to be confused with the Mac app store. iPad and Mac have two different operating systems, iOS and Mac OS, so they have separate stores. Games can be released both in the iOS and the Mac store. There could also be some confusion between Google Play and Chrome Web Store. Google Play contains all the apps available for smartphones that have Google's Android operating system. The Chrome Web Store lets you add apps to your Google Chrome browser. So there are quite a few distribution channels to pick from and here we will have a quick look at Google Play, the iOS App store, and the Chrome Web Store. Google Play Google Play is the Android's default app shop and the biggest competitor of the iOS App Store. If you wish to become an Android app developer, there is a $25 fee and a developer distribution agreement that you must read. In return for the entrance fee and signing this agreement, they allow you to make use of their virtual shelves and have all its benefits. You can set your price as you please, but for every game you sell, Google will cash in about 30 percent. It is possible to do some geological price discrimination. So you could set your price at, let's say €1 in Belgium, while charging €2 in Germany. You can change your price at any time; however, if you release a game for free, there is no turning back. The only way to monetize this app afterwards is by allowing in game advertising, selling add-ons, or creating an in-game currency that can be bought with real money. Introducing an in-game currency that is bought with real money can be a very appealing format. A really successful example of this monetizing scheme can be found in The Smurfs games. In this game you build your own Smurf village, complete with Big Smurf, Smurfette, and a whole lot of mushrooms. Your city gets bigger as you plant more crops and build new houses, but it is a slow process. To speed it up a bit you can buy special berries in exchange for real money, which in turn allows you to build exclusive mushrooms and other things. This monetization scheme becomes very popular as has been shown in games such as League Of Legends, PlanetSide 2, World of Tanks, and many others. For Google Play apps, this in-app payment system is supported by Android's Google Checkout. In addition, Google allows you access to some basic statistics for your game, such as the number of players and the devices on which they play, as shown in the following diagram: Image Information such as this allows you to redesign your game to boost your success. For example, you could notice if a certain device doesn't have that many unique users, even though it is a very popular device and is bought by many people. If this is the case, maybe your game doesn't looks nice on this particular smartphone or tablet and you should optimize for it. The biggest competitor and initiator of all apps is the iOS App Store, so let's have a look at this. iOS App Store The iOS App Store was the first of its kind and at the time of writing this book, it still has the biggest revenue. In order to publish apps in the iOS App Store, you need to subscribe to the iOS Developer Program, which costs $99 annually—almost four times the subscription fee of Google Play. In effect, they offer about the same thing as Google Play does; as you can see in this short list: You pick your own prices and get 70 percent of sales revenue You receive monthly payments without credit card, hosting, or marketing fees There is support and adequate documentation to get you started More importantly, here are the following differences between Google Play and the iOS App Store: As mentioned earlier, signing up for Google Play is cheaper. The screening process of Apple seems to be more strict than that of Google Play, which results in a longer time to reach the market and a higher chance of never even reaching the market. Google Play incorporates a refund option that allows the buyer of your app to be refunded if he or she uninstalls the app or game within 24 hours. If you want your game to make use of some Android core functionalities, this is possible since the platform is open source. Apple, on the other hand, is very protective of its iOS platform and doesn't allow the same level of flexibility for apps. This element might not seem that important for games just yet, but it might be for very innovative games that do want to make use of this freedom. iOS reaches more people than Android does, though the current trend indicates that this might change in the near future. There seem to be significant differences in the kind of people buying Apple devices and the users of smartphones or tablets with Android OS. Apple fans tend to have a lower barrier towards spending money on their apps than Android users do. In general, iPads and iPhones are more expensive than other tablets and smartphones, attracting people who have no problem with spending even more money on the device. This difference in target group seems to make it more difficult for Android game developers to make money from their games. The last option for selling apps that we will discuss here is the Chrome Web Store. The Chrome Web Store The Chrome Web Store differs from Google Play and the iOS App Store in that it provides apps specifically for the Chrome browser and not for mobile devices. The Chrome Store offers web apps. Web apps are like applications you would install on your PC, except web apps are installed in your browser and are mostly written using HTML, CSS, and JavaScript, like our ImpactJS games. The first thing worth noticing about the Chrome Store is the one-time $5 entrance fee for posting apps. If this in itself is not good enough, the transaction fee for selling an app is only 5 percent. This is a remarkable difference to both Google Play and the iOS App Store. If you are already developing a game for your own website and packaged it as an app for Android and/or Apple, you can just as well launch it on the Chrome Web Store. Turning your ImpactJS game into a web app for the Chrome Store can be done using AppMobi, yet Google itself provides detailed documentation on how to do this manually. One of the biggest benefits of the web app is the facilitation of the permission process. Let's say your web app needs the location of the user in order to work. While iPad apps ask for permission every time they need location data, the web app asks permission only once: at installation time. Furthermore, you have the same functionalities and payment modalities as in Google Play, give or take. For instance, there is also the option to incorporate a free trial version, also known as a freemium. A freemium model is when you allow downloading a demo version for free with the option of upgrading it to a full version for a price. The Smurfs game also uses the freemium model, albeit with a difference. The entire game is free, but players can opt to pay real money to buy things that would otherwise cost them a lot of time to acquire. In this freemium model, you pay for convenience and unique items. For instance, in PlanetSide 2, acquiring a certain sniper rifle might take you several days or $10, depending on how you choose to play the freemium game. If you plan on releasing an ImpactJS game for Android, there is no real reason why you wouldn't do so for the Chrome Web Store. That being said, let's have a quick recap: The time when the iOS app store was the only app store out there is long gone; there is an impressive repertoire of app stores to choose from, which includes Firefox Marketplace, Intel AppUp Center, Windows Phone Store, Amazon Appstore, SlideMe, Mobango, Getjar, Appsfire, Google Play, among others. The biggest app stores are currently Google Play and the iOS App Store. They differ greatly on several fronts, of which the most important ones are: Subscription fee Screening process Type of audience they attract The Chrome Web Store sells web apps that act like normal apps but are available in the Chrome browser. The Chrome Web Store is cheap and easy to subscribe to. You must definitely have a go at releasing your game on this platform. In-game advertising In-game advertising is another way to make money with your game. In-game advertising is a growing market and is currently already being used by major companies; it was also used by Barack Obama in both his 2008 and 2012 campaigns, as shown in the following in-game screenshot: Image There is a trend towards more dynamic in-game advertising. The game manufacturers make sure there is space for advertising in the game, but the actual ads themselves are decided upon later. Depending on what is known about you, these can then change to become relevant to you as a player and a real-life consumer. When just starting out to build games, in-game adverting doesn't get that spectacular though. Most of the best known in-game advertisers for online games don't even want their ads in startup games. The requirements for Google AdSense are the following: Game plays: Minimum 500,000 per day Game types: Web-based Flash only Integration: Must be technically capable of SDK integration Traffic source: Eighty percent of traffic must be from the US and the UK Content: Family-safe and targeted at users aged 13 and over Distribution: Must be able to report embedded destinations and have control over where the games are distributed The requirements for another big competitor, Ad4Game, aren't mild either: At least 10,000 daily unique visitors Sub-domains and blogs are not accepted The Alexa rank should be less than 400,000 Adult/violent/racist content is not allowed If you are just starting out, these prerequisites are not good news. Not only because you need such a large number of players before even starting the advertising, but also because currently all support goes to Flash games. HTML5 games are not fully supported yet, though that will probably change. Luckily, there are companies out there that do allow you to start using advertising even though you don't have 10,000 visitors a day. Tictacti is one of those companies. Once again, almost all support goes to the Flash games, but they do have one option available for an HTML5 game:pre-roll. Pre-roll simply means that a screen with an ad appears before you can start the game. Integration of the pre-roll advertising is rather straightforward and does not require a change to your game, but to your index.html file, as in the following example from Tictacti: code While adding this to your game's index.html file, you fill out your own publisher ID and you are basically ready to go. Tictacti is similar to Google Analytics, and it also provides you with some relevant information about the ads on your game's website, as shown in the following diagram: Image Be careful, however, pre-roll advertising is one of the most intruding and annoying kinds of advertising. Technically, it is not even in-game advertising at all, since it runs before you play the game. If your game is not yet well established enough to convince the player to endure the advertising before being able to play, don't choose this option. Give your game some time to build a reputation before putting your gamers through this. As the last option, we will have a look at selling your actual distribution rights with MarketJS. But let's first briefly recap on in-game advertising: In-game advertising is a growing market. Even Barack Obama made use of in-game billboards to support his campaign. There is a trend towards more dynamic in-game advertising—using your location and demographic information to adapt the ads in a game. Currently, even the most accessible companies that offer online in-game advertising are focused on Flash games and require many unique visitors before even allowing you to show their ads. Tictacti is a notable exception, as it has low prerequisites and an easy implementation; though advertising is currently limited to pre-roll ads. Always take care to first build a positive reputation for your game and allow advertisements later. Selling distribution rights with MarketJS The last option we will investigate in this chapter is selling your game's distribution rights. You can still make money by just posting your game to all the app stores and on your own website, but it becomes increasingly difficult to be noticed. Quality can only prevail if people know it is out there, thus making a good game is sometimes not enough—you need marketing. If you are a beginner game builder with great game ideas and the skills to back it up, that's great, but marketing may not be your cup of tea. This is where MarketJS comes into play. MarketJS acts as an intermediate between you as the game developer and the game publishers. The procedure is simple once you have a game: You sign up on their website, http://www.marketjs.com. Upload the game on your own website or directly to the MarketJS server. Post your game for publishers to see. You set several options such as the price and contract type that would suit you the best. You have five contract options: Complete distribtution contract: Sell all your distribution rights to the game. Exclusive distribution partner contract: Here you restrict yourself to work with one distributor but still retain the rights to the game. Non-exclusive contract: Here, any distributor can buy the rights to use your game, but you can go on selling rights as long as you want. Revenue share: Here you negotiate on how to split the revenues derived from the game. Customized contract: This can basically have any terms. You can choose this option if you are not sure yet what you want out of your game. A part of the webpage on which you fill out your contracting preferences is shown in the following screenshot: Image After you have posted a demo, it is a matter of waiting for a publisher to spot it, get stunned by its magnificence, and offer to work with you. The big contribution of MarketJS to the gaming field is this ability to let the game developer focus on developing games. Someone else takes care of the marketing aspect, which is a totally different ballgame. MarketJS also offers a few interesting statistics such as the average price of a game on their website, as shown in the following diagram. It grants you some insight on whether you should take up game developing as a living or keep doing it as a hobby. Image According to MarketJS, prices for non-exclusive rights average between $500 and $1000, while selling exclusive rights to a game range somewhere between $1500 and $2000. If you can build a decent game within this price range, you are more than ready to go: MarketJS is a company that brings game distributers and developers closer together. Their focus is on HTML5 games, so they are great if you are a startup ImpactJS game developer. They require no subscription fee and have a straightforward process to turn your game into a showcase with a price tag. Summary In this article we have taken a look at some important elements while considering your game development strategy. Do you wish to adapt a shotgun approach and develop a lot of games in a short time span? Or will you use the sniper strategy and only build a few, but very polished games? You also need to decide upon the audience you wish to reach out to with your game. You have the option of building a game that is liked by everyone, but the competition is steep. Making money on the application stores is possible, but for Android and Apple there are registration fees. If you decide to develop apps, it is worth giving the Chrome Web Store a try (it runs web apps). In-game advertising is another way to fund your efforts, though most companies offering this service for online games have high prerequisites and support Flash games more than they do the newer HTML5 games. One of the most promising of monetization schemes is the freemium model. Players are allowed to freely play your game but they pay real money for extras. This is an easily tolerated model since the game is essentially free to play for anyone not willing to spend money, and no annoying advertising is present either. A combination of in-game advertising and freemium is possible as well: people annoyed by the advertising pay a fee and in return they are not bothered by it anymore. A final option is leaving the marketing aspect to someone else by selling your distribution rights with the help of MarketJS. They aim for HTML5 games and this option is especially useful for the beginner game developer who has difficulty in marketing his or her game. Resources for Article : Further resources on this subject: HTML5: Developing Rich Media Applications using Canvas [Article] Flash 10 Multiplayer Game: The Lobby and New Game Screen Implementation [Article] Building HTML5 Pages from Scratch [Article]
Read more
  • 0
  • 0
  • 4079

article-image-creating-custom-hud
Packt
29 Apr 2013
5 min read
Save for later

Creating a Custom HUD

Packt
29 Apr 2013
5 min read
(For more resources related to this topic, see here.) Mission Briefing In this project we will be creating a HUD that can be used within a Medieval RPG and that will fit nicely into the provided Epic Citadel map, making use of Scaleform and ActionScript 3.0 using Adobe Flash CS6. As usual, we will be following a simple step—by—step process from beginning to end to complete the project. Here is the outline of our tasks: Setting up Flash Creating our HUD Importing Flash files into UDK Setting up Flash Our first step will be setting up Flash in order for us to create our HUD. In order to do this, we must first install the Scaleform Launcher. Prepare for Lift Off At this point, I will assume that you have run Adobe Flash CS6 at least once beforehand. If not, you can skip this section to where we actually import the .swf file into UDK. Alternatively, you can try to use some other way to create a Flash animation, such as FlashDevelop, Flash Builder, or SlickEdit; but that will have to be done on your own. Engage Thrusters The first step will be to install the Scaleform Launcher. The launcher will make it very easy for us to test our Flash content using the GFX hardware—accelerated Flash Player, which is what UDK will use to play it. Let's get started. Open up Adobe Flash CS6 Professional. Once the program starts up, open up Adobe Extension Manager by going to Help | Manage Extensions.... You may see the menu say Performing configuration tasks, please wait.... This is normal; just wait for it to bring up the menu as shown in the following screenshot: Click on the Install option from the top menu on the right—hand side of the screen. In the file browser, locate the path of your UDK installation and then go into the BinariesGFxCLICK Tools folder. Once there, select the ScaleformExtensions.mxp file and then select OK. When the agreement comes up, press the Accept button; then select whether you want the program to be installed for just you or everyone on your computer. If Flash is currently running, you should get a window popping up telling you that the program will not be ready until you restart the program. Close the manager and restart the program. With your reopened version of Flash start up the Scaleform Launcher by clicking on Window | Other Panels | Scaleform Launcher. At this point you should see the Scaleform Launcher panel come up as shown in the following screenshot: At this point all of the options are grayed out as it doesn't know how to access the GFx player, so let's set that up now. Click on the + button to add a new profile. In the profile name section, type in GFXMediaPlayer. Next, we need to reference the GFx player. Click on the + button in the player EXE section. Go to your UDK directory, BinariesGFx, and then select GFxMediaPlayerD3d9.exe. It will then ask you to give a name for the Player Name field with the value already filled in; just hit the OK button. UDK by default uses DirectX 9 for rendering. However, since GDC 2011, it has been possible for users to use DirectX 11. If your project is using 11, feel free to check out http://udn.epicgames.com/Three/DirectX11Rendering.html and use DX11. In order to test our game, we will need to hit the button that says Test with: GFxMediaPlayerD3d9 as shown in the following screenshot: If you know the resolution in which you want your final game to be, you can set up multiple profiles to preview how your UI will look at a specific resolution. For example, if you'd like to see something at a resolution of 960 x 720, you can do so by altering the command params field after %SWF PATH% to include the text —res 960:720. Now that we have the player loaded, we need to install the CLIK library for our usage. Go to the Preferences menu by selecting Edit | Preferences. Click on the ActionScript tab and then click on the ActionScript 3.0 Settings... button. From there, add a new entry to our Source path section by clicking on the + button. After that, click on the folder icon to browse to the folder we want. Add an additional path to our CLIK directory in the file explorer by first going to your UDK installation directory and then going to DevelopmentFlashAS3CLIK. Click on the OK button and drag—and—drop the newly created Scaleform Launcher to the bottom—right corner of the interface. Objective Complete — Mini Debriefing Alright, Flash is now set up for us to work with Scaleform within it, which for all intents and purposes is probably the hardest part about working with Scaleform. Now that we have taken care of it, let's get started on the HUD! As long as you have administrator access to your computer, these settings should be set for whenever you are working with Flash. However, if you do not, you will have to run through all of these settings every time you want to work on Scaleform projects.
Read more
  • 0
  • 0
  • 4462
